Description
NEW Standard Ablation Profiles
Refraction
-
- Optimized ablation mode from 12.5 um per D
- Q-factor correction
- Multifocal refraction with wide peripherical zone for low accommodation compensation
Presbyopia
-
- Central zone optimized for vision at distance
- Side zone for close view
Advanced PTK
-
- Initial stage of TransPRK
- Treatment of cornea surface disorders
Technical Specifications
- Indications Range: Myopia up to 13 D, hyperopia up to 7 D, astigmatism up to 10 D
- Tracking: By pupil, limbal ring or scleral vessels
- Aiming: By pupil, limbal ring
- Ablation Depth: From 12.5 um per D
- Roughness: 190 nm
- Treatment Time: From 1.19 sec per D
- Laser Repetition Rate: 1100 Hz or 500 Hz
- Laser Wavelength: 193 nm
- Laser Beam Diameter: 0.9 mm
- Laser Beam Profile: Super Gauss
- Access Card: Not required
- Supported Diagnostic Instruments: Topcon KR-1W, Visionix VX 120, Tomey TMS-5
- Cold Start Time: 30 min
- Footprint: 72 x 135 cm (28 x 53 in)
