Description

Approximate net weight: kg 150 (330 lbs.)

Maximum Patient weight: kg 300 (660lbs)

Tension : 220-240V (110)

Frequency: 50-60Hz

Power: 660VA

Battery Voltage: 24Vdc

Rechargeable system built in: Yes

Battery level display: Yes

Battery working cycle: approx 1 week (under standard working conditions)

Mode operation for the actuators: 2′ work under load / 18′ rest

Maximum Patient height: 1000 mm

Minimum Patient height: 680 mm

Column stroke: 320 mm

Backrest tilt angle: 0° (flat) / 82°

Leg rest tilt angle: 0° (flat) / 62°

Trendelenburg angle: -18°/-10° (total tilt angle 28°)

Seat width: 600 mm

Wheels: 3 positions commanded by foot pedal (brake/steer/neutral)

Hand control: Full control of the actuators

Headrest: 3 movements useful for a complete possibility of regulations

Optional: Armrest, Oxygen pipe
