Description

Technical specifications:

Laser Beam Delivery: Coaxial delivery with slit illumination

Laser spot Diameter: Continuousely adjustable par focal system with

variable spot size from 50-1000µ at coroneal plane.

Magnification Ratio: 6, 10, 16, 25 & 40x

Standard Slit: 0°, 45° & 90°

Illumination: 12V-30V, Brightness continuously adjustable

Slit Length Adjustment: Adjustable in step of 1, 3, 5, 8, 10 & 14mm

Slit Width Adjustment: Continuously adjustable from 1-14 mm

Laser Spot Size Display: 7 segment LED display in slit lamp

Physician Saftey Filters: Ultra clear view saftey filter permanently integrated

Micro Manipulator movements: 360°

Weight (without packing): 10 Kg

Slit Lamp Filters: Heat absorbing, green (red free), Cobalt blue



Movement Ranges:

Longitudinal (In/Out): 99mm

Lateral (Left/Right): 118mm

Vertical (Up/Down): 30mm

Chin Rest Range: 90mm

Dimensions: 530(L)x380(W)x600(H) mm
