Description
Specifications
| Laser SLT | Q-switched 532 nm Frequency Doubled Nd:YAG |
| Energy per pulse | 0.2 to 2.0 mJ, quasi continuously |
| Size treatment spot | 400 μm in aiming beam focus |
| 400 µm in max. Repetition rate | > 10 Hz |
| Pulse width | 3 ns |
| Aiming beam | Red, diode 635 nm / 1 mW, adjustable |
| Laser protection filter | permanent |
| Radiation divergence | 3.2° |
| Laser class | 3b / 532 nm, E = 2.5 mJ Aiming beam: 635 nm, P < 1 mW |
| Laser Nd:YAG | Q-switched 1064 nm Nd:YAG |
| Energy per pulse | 0.3 to 12 mJ, quasi continuous |
| Size treatment spot | 400 μm on Focus |
| Max. Repetition rate | 0.5 to 2 Hz |
| Pulse width | 4ns +4/-0ns |
| Aiming beam | red diode 635 nm / 1 mW, variable |
| Laser protection filter | permanent |
| Beam divergence | 0.5 m² |
| Power supply | 100 to 240 V, 50/60 Hz, 600 Watt |
| Laser class | 3b / 532 nm, E = 2.5 mJ aiming beam: 635 nm, P < 1 mW |
