SK MED LS-1B Portable Slit Lamp
SLIT LAMPS
SK MED LS-1B Portable Slit Lamp
€1,000.00
The LS-1B is a device provided with carrying case, battery charger, forehead support and user manual.
Product Features
- Two magnification with selector switch: 10x, 16x
- Operating distance of the slit lamp should be 80mm (16X magnification) and 100mm (10X magnification).
- Ability to adjust the distance of the eyepieces from 49mm to 75mm
- Be able to adjust the diopters of the eyepieces: ±7D
- Filters: Neutral density (ND), Redfree, Cobalt blue
- Thermal LED light source with a color temperature of 3500k.
- Operating voltage of the Led source should be 15VA, AA Battery
- iPhone Adaptable: View and capture high definition visuals using the iPhone adapter
Type : Binocular direct vision type, erected real image
Eyepiece: Converging binocular at 13°
Magnification: LS-1A:10X, LS-1B:10X/16X
Working Distance: 80mm(16X) / 100mm(10X)
Field of View: ø10mm(16X) / ø15mm(10X)
Interpupillary: 49-75mm
Diopter Adjustment: ±7D
Slit Size: 0.1mm*12mm / 0.2mm*8mm/ 0.8mm 12mm
Spot Size: o1/ 05/ ø12mm
Slit Angle: Horizontal, ±60°
Filter: Neutral Density
Red-free: Cobalt Blue
Light Resource: Warm LED
Brightness: ≥300000Lux
Illumination control: Continuously Adjustable
Battery Type: 2 AA batteries
Operating Time: ≥4 Hours
Dimensions: 320*310*205mm
Net Weight: Approx 835g
