Description
Specification
Floor stand: Four 360° rotating castors (Ø150 mm), parking brake
Load: Floor stand max. 8.0 kg from microscope dovetail ring interface
Direct illumination with 2 LED lamps
Main light:
- Integrated LED illumination system for intensive uniform illumination of the field of view
- Continuously adjustable brightness with halogen-like color temperature
CoAx 4 coaxial illumination:
- Illumination unit for generating a clear and stable Red Reflex, decreasing stray light through the sclera and increasing the image contrast
Adjustable CoAx 4:
- Diameter of coaxial illumination is adjustable between 4 and 23 mm via footswitch
- Fine focus: Available for assistant and integrated camera or external 1/3 camera with C-mount interface
OpenArchitecture:
- Prepared for integration of video camera systems, digital recording and imaging systems such as EnFocus OCT and monitors
Connectors:
- Four built-in video connectors for transfer of video and control data (DIV Out, DIV In, C-video Out,
HD-SDI Out) - Internal power supply 12 VDC, 19 VDC, 24 VDC and AC terminals
Power connection: 600 VA 50/60 Hz
