Probe’s Characteristics

B Scan



• Frequency: 10MHz, Magnetic driven, noiseless

• Scanning Mode: Sector Scanning

• Magnify: Multi continuous magnification, Real-Time magnification

• Resolution: Lateral ≤0.3mm, Vertical≤0.2mm

• Geometry Position Precision: ≤5%, Vertical≤3%

• Depth: 60mm

• Enhance the part of vitreous body retinal

• Gain of Probe: 30dB-105dB

• Scanning Angle: 53⁰

• Gray Scale: 256

• False Color: Multi Colors

• Measurement Type: Multigroup distances, perimeters and areas

• Image Post processing: Multiple curves processing, Pseudo-color processing curve

• Movies: 100 image movie, AVI JPG format image output



A Scan



• Frequency: 10MHz, with LED

• Depth: 40mm

• Precision: ±0.05mm

• Measurement: Anterior chamber depth, lens thickness, vitreous body length, total length and average

• Eye Mode: Phakic/Aphakic/Dence/Various IOL

• IOL Formula: SRK-II, SRK-T, HOFFER-Q, HOLLADAY, BINKHORST-II, HAIGIS

• Stat. Calculation: Average and standard deviation

• Store: 10 Scanning results for each eye



Full Scale UBM



• Frequency: 50MHz

• Scanning Mode: Wide Range Sector, Scanning Mode, Undistorted, Sulcus-to sulcus

• Scanning Range: 16mm*9mm; 10*6.5mm

• Vertical Precision: ≤40μm

• Lateral Precision: ≤40μm

• Scanning Lines: 1024 Lines, 15μm between each lines

• Geometry Location Precision: Vertical ≤3%, Lateral ≤3%, Non data interpolation, none distortion Imaging.

• Display Mode: UBM,UBM+A

• System Performance: It have a special independent 50μm ultrasonic amplification system make the anterior segment image clearer

• Windows Platform: Windows System



Others



• Display Mode: B,B+B,B+A,A

• Hint: Preset keyword

• Case Search: Multi-keywords

• Working Platform: Windows System

• User Defined report template
